Yamaha TFRACK Rackmount Digital Mixer
The Yamaha TF-Rack is a rack-mountable digital mixer with a touchscreen display and the option to add the Tio1608-D I/O rack for up to 40 input channels. The TF-Rack may be used for live recording as well as live sound reinforcement, with 34x34 channel digital recording and playback via USB 2.0 using a computer and your favourite DAW software, and 2x2 channel recording and playback using any USB storage device. There are 16 analogue XLR/TRS combo mic/line inputs with 48V phantom power on the TF-Rack console, as well as an analogue RCA stereo line input and 16 analogue XLR outputs. Each combo input channel has a D-PRE microphone preamp that can be recalled, as well as EQ and two dynamics processors. The console also has eight powerful FX processors with patches ranging from reverb and delay to modulation effects like flanger and chorus, as well as utility processing like 3-band multi-band compression. For advanced multi-tracking and virtual sound check, the TF-Rack comes with Steinberg's Nuendo Live.
- All-in-One rack-style digital mixer
- Inputs: 16 mic/line (XLR/TRS combo) + 1 stereo line (RCA pin)
- Output: 16 (8 XLR + 8 TRS phone)
- Channels: 40 (32 mono + 2 stereo + 2 return)
- Aux Buses: 20 (8 mono + 6 stereo)
- Stereo Buses: 1
- Sub Buses: 1
