TOA TU632M Driver Unit

The Toa TU-632M is a highly intelligible driver unit suited to public address announcement applications. This audio accessory is used in combination with a suitable horn (optional). Powder-coated finish and stainless steel screws ensure the unit's weatherproof capability.

SPECIFICATIONS:

- Rated Input : 30 W
- Weight : 1.8 kg (3.97 lb)
- Applicable Horns : TH-652
- Line Voltage : 100 V line or 70 V line
- IP Code : IP65 (When a driver is operated with a horn.)
- Horn Coupling : 1 - 3/8 18 threads (inch screw)
- Polarity : Hot : Black, Com : White
- Dimensions : Φ139 × 149 (D) mm (Φ5.47" × 5.87")
- Frequency Response : 150 Hz - 6,000 Hz (When operated with JIS C 5504 standard horn.)
- Output Sound Pressure Level : 110 dB (1 W, 1 m) (When operated with JIS C 5504 standard horn.)
- Operating Temperature : -20°C to +55°C (-4°F to +131°F) (must be free from dew condensation)
- Rated Impedance : 100 V line : 330 Ω (30 W), 670 Ω (15 W), 1 kΩ (10 W), 2 kΩ (5 W)
                                       70 V line : 170 Ω (30 W), 330 Ω (15 W), 670 Ω (7.5 W), 1 kΩ (5 W), 2 kΩ (2.5 W)
- Finish : Upper Cover : Aluminum, White, powder coating
                Unit Case : HIPS. White
                Screws : Stainless steel
                Speaker cable : Polyvinyl chloride insulated cabtyre cable
- Dimensions : (6 mm (0.24") in diameter, 450 mm (17.72") in length)
- Color : White
