MIPRO ACT747/ACT7T Wireless Lavalier System

The MIPRO's ACT747/ACT7T is a wireless microphone system that includes ACT747 quad channel receiver and four ACT 7T wireless lavalier transmitter. The ACT747 is a EIA standard 1U rack-mountable metal receiver, with 104 selectable frequencies and 16 preset compatible channels per band. Even better, this receiver features industry’s only full-color VFD screen delivers a bright, clear viewing in day or night environments.

ACT747 UHF Quad-Channel True Diversity Receiver

• EIA standard 1U rack-mountable metal receiver.
• Advanced true diversity technology for best reception quality.
• 104 selectable frequencies and 16 preset compatible channels per band. More with multiple bands.
• Industry’s only full-color VFD screen delivers a bright, clear viewing in day/night environments.
• Displays Group, Channel, Frequency, Performer’s Name, transmitter battery level, RF, Audio, SQ level meters, diversity operation, RF interference warning indicator and Lock status.
• One-touch Autoscan for a clear, interference-free frequency.
• One-touch ACT™ syncs the transmitter and receiver frequency automatically.
• Dual "PiloTone & NoiseLock" circuits minimize interference.
• MIPRO RCS.Net software allows real-time computer set up, control and monitoring.
• Industry’s only RF interference warning indicator and control for management.
• Displays all pertinent parameters on the same screen for easy control and monitoring.
• All controls are intuitive and easily setup via a single rotary knob.

ACT 7T Wireless Lavalier Transmitter

• Sturdy, compact magnesium alloy housing.
• ACT™ syncs the transmitter and receiver frequency automatically.
• Pilotone squelch for interference-free operation.
• Built-in transmitter gain adjustment.
• Impedance selectable switch for microphone or guitar.
• 4-pin mini XLR connector is compatible with all MIPRO lavalier, headworn microphones and instrument cable.
• Silent on/off switch.
• 4-segment battery status meter.
• LCD displays group, channel & error message code.
• 20-hour battery life per 2 'AA' alkaline batteries.
