MIPRO ACT71/ACT70H Wireless Handheld System

The MIPRO's ACT71/ACT70H is a wireless microphone system that includes ACT71 single channel receiver and a ACT 70H handheld wireless microphone transmitter. The MIPRO ACT71 features cutting-edge technology and design, and audio professionals praise the RF stability. The transmitter is outfitted with MIPRO's newest ECM capsule modules, which provide the listener with an extraordinarily clear and accurate auditory image. They're perfect for broadcast, live sound production, conferences, and other large-scale events.

ACT71 UHF Wide Band Single-Channel True Diversity Receiver

• EIA standard 1/2U rack-mountable metal chassis with excellent heat dissipation & RF shielding characteristics.
• The wideband receiver has 400 preset channels with 1-set of user-defined group that saves up to 16 channels. Auto Scan function allows quick search for an interference-free working channel.
• UHF PLL synthesized circuit and advanced RF and IF circuitry to improve anti-interference characteristics and increase the number of interference-free channels available.
• World’s first ACT™ function provides precise and rapid frequency sync to the transmitters.
• True diversity receiving for best reception quality. Dual "PiloTone & NoiseLock" circuits minimize interference.
• Receiver provides bias voltage for MIPRO antenna systems to enhance reception range and signal stability.
• Industry’s only full-color VFD screen delivers a bright, clear viewing in day or night environments with automatic bright (working) and dim (standby) displays during performance.
• All controls are intuitive and easily set up via a single rotary knob.
• Industry’s only RF interference warning indicator for proper adjustments of the SQ level. Increase sensitivity to extend the receiving range; decrease the sensitivity to reduce interference.
• Single channel or mixed output, switchable between three output levels for the best sound quality options.
• MIPRO RCS.Net software allows real-time computer setup, control and monitoring.
• Built-in 100~240V AC switching power supply ensures system safety and stability.

ACT 70H Handheld Transmitter

• Innovatively designed metal housing in MIPRO’s distinctive aesthetic and ergonomic style.
• Interchangeable capsule module with premium condenser or dynamic options for easy and fast changeovers. The unique multi-layered metal grille protects the capsule against impact, rolling and pop noise, ensuring clarity of sound. The upper grille is easy to detach for cleaning and hygiene practice.
• Patented capsule suspension design virtually eliminates vibration and handling noises.
• Backlit LCD displays all operational parameter information.
• Five selectable gain settings with microphone input sensitivity of 0 dB level. Proprietary high-definition modulation circuit sustains high SPL without distortion.
• Switchable Manual / Disable audio mute options.
• World’s first ACT™ function provides precise and rapid frequency sync to the receiver. Switchable high / Low power options.
• The bottom housing with built-in high-efficiency antenna features power switch, mute and setup buttons for programmable gain, limiter, mute and RF output power.
• Patented end-cap cover with color-coded channel identification clips onto the mic and can be reversed to allow shielding of power on/off or mute switches during performance. Detach the end-cap cover for parameters set-up.
