MIPRO ACT52/ACT50T Wireless Lavalier System

The MIPRO's ACT52/ACT50T is a wireless microphone system that includes ACT52 UHF half U dual channel diversity receiver with two ACT50T bodypack wireless microphone. The ACT52H is a EIA standard 1/2U rack-mountable metal chassis receiver with stable performance. All controls of this receiver are intuitive and easily operating via electronic buttons, preventing accidental operation, and each receiver presets 6 groups, and each group presets 8 interference-free channels. ACT50T is a miniature bodypack transmitter is a small and lightweight transmitter with sturdy metal housing. The transmitter has a mute switch, a mini-XLR connector, an antenna on the top, and a back-lit LCD panel with numerous metrics shown. The transmitter can be worn in either an up or down position with the adjustable belt clip.

ACT52 UHF Half U Dual Channel Diversity Receiver

• EIA standard 1/2U rack-mountable metal chassis for personal use.
• All controls are intuitive and easily operating via electronic buttons, preventing accidental operation.
• Full-color VFD (vacuum fluorescent display) displays all pertinent parameters on the same screen. Automatic dim for stand-by and lit during performance.
• Each receiver presets 6 groups, and each group presets 8 interference-free channels. A total of 48 preset channels per band.
• World’s first ACT™ function provides precise and rapid frequency sync to the transmitters.
• Advanced diversity receiving circuit for the best elimination of signal dropout and the “PiloTone & NoiseLock” dual-squelch circuits prevent noise interference.
• Three switchable output levels. Output level is accurately pre-adjusted to equal to the microphone capsule sensitivity and ensures optimal performance
• Receiver provides bias for booster where MIPRO antenna systems can be added for extended receiving range and stability
• Stable performance, easy installation and more non-interference channels ideal for stage and PA applications.

ACT50T Bodypack Transmitter

• Lightweight, compact size with sturdy metal housing.
• Antenna, mute button and XLR input connector are located on the top of transmitter.
• Backlit LCD displays various parameters and status.
• Innovatively designed battery cover allows easy access to operate buttons and prevents accidental operation.
• Mute button and remote-control jack is equipped for easy activation of mute function.
• PLL-synthesized technology enhances frequency stability and an interference-free working channel can be synchronized quickly and precisely by MIPRO’s patented ACT™ function.
• Can be directly matched to high-low input impedance for microphone and guitar without switching and the input sensitivity is adjustable.
• Mini-XLR input connector for quick-lock or screw-lock with lavaliere or headworn microphones and guitar.
• High efficiency, low power consumption and low spurious emissions transmitting circuit for long battery hours of 2 AA batteries.
• Adjustable belt clip allows wearing transmitter in up or down position.
