MIPRO ACT52/ACT50H Wireless Handheld System

The MIPRO's ACT52/ACT50H is a wireless microphone system that includes ACT52 UHF half U dual channel diversity receiver with two ACT50H handheld wireless microphone. The ACT52H is a EIA standard 1/2U rack-mountable metal chassis receiver with stable performance. All controls of this receiver are intuitive and easily operating via electronic buttons, preventing accidental operation, and each receiver presets 6 groups, and each group presets 8 interference-free channels. ACT50H is a handheld transmitter with unique multi-layered steel grilles that protect the capsule from impact, anti-roll, and pop noise while still providing transparent sound clarity. It has interchangeable capsule modules with quality condenser or dynamic choices, which proprietary true condenser capsule provides high fidelity, wide dynamic range, excellent feedback rejection, and transparent sound quality.

ACT52 UHF Half U Dual Channel Diversity Receiver

• EIA standard 1/2U rack-mountable metal chassis for personal use.
• All controls are intuitive and easily operating via electronic buttons, preventing accidental operation.
• Full-color VFD (vacuum fluorescent display) displays all pertinent parameters on the same screen. Automatic dim for stand-by and lit during performance.
• Each receiver presets 6 groups, and each group presets 8 interference-free channels. A total of 48 preset channels per band.
• World’s first ACT™ function provides precise and rapid frequency sync to the transmitters.
• Advanced diversity receiving circuit for the best elimination of signal dropout and the “PiloTone & NoiseLock” dual-squelch circuits prevent noise interference.
• Three switchable output levels. Output level is accurately pre-adjusted to equal to the microphone capsule sensitivity and ensures optimal performance
• Receiver provides bias for booster where MIPRO antenna systems can be added for extended receiving range and stability
• Stable performance, easy installation and more non-interference channels ideal for stage and PA applications.

ACT50H Handheld Microphone Transmitter

• Rugged, ergonomically designed metal housing.
• Unique sturdy multi-layered steel grilles not only protect the capsule against impact, anti-roll and pop noise, but also ensure transparent sound clarity.
• Interchangeable capsule module with premium condenser or dynamic options for easy and fast changeovers.
• Proprietary true condenser capsule exhibits high fidelity, wide dynamic range, fast transient responses, good feedback rejection, accurate sound image characteristics, transparent sound quality, and withstands maximum SPL.
• Proprietary dynamic capsule exhibits low handling & impact noise characteristics.
• Proprietary lockable silent on/off switch to avoid accidental power-off during performance.
• Patented, integrated grille and battery housing design enable fast and easy 2 AA battery installation and replacement.
• Impact-resistant battery compartment holds 2 AA batteries with color-coded rings for easy channel identification on stage.
• LCD displays working channel, battery status indicator, and error code messages
• Low spurious PLL-synthesized technology enhances frequency stability and reliability.
• One-touch ACT syncs the transmitter and receiver frequency automatically.
• Maximum 140dB SPL is achieved by the proprietary high dynamic range modulation circuitry.
