MIPRO ACT51/ACT50T Wireless Lavalier System

The MIPRO's ACT51/ACT50T is a wireless microphone system that includes a ACT51 UHF half-U single channel diversity receiver and a ACT80T bodypack transmitter. ACT51 is a single channel half rack design receiver. It features "AutoScan” and ACT (Automatic Channel Targeting) channel setup technology, up to 8 preset compatible systems per band, and diversity technology for optimum reception. ACT50T is a miniature bodypack transmitter is a small and lightweight transmitter with sturdy metal housing. The transmitter has a mute switch, a mini-XLR connector, an antenna on the top, and a back-lit LCD panel with numerous metrics shown. The transmitter can be worn in either an up or down position with the adjustable belt clip.

ACT51 UHF Half-U Single Channel Diversity Receiver

• Single & Dual Channels 1/2-rack design.
• Up to 8 preset compatible systems per band.
• Industry’s only color VFD (Vacuum Florescent Display) delivers a very bright light with exceptionally clear contrast for clear viewing in day/night environments.
• Industry’s only interference indicator.
• Features MIPRO’s patented and now, industry standard “AutoScan” and ACT (Automatic Channel Targeting) channel setup technology.
• Diversity technology for optimum reception.
• Dual-squelch "PiloTone & NoiseLock" circuits minimize interference.
• Proprietary high performance RF filter and circuitry improve anti-interference characteristics and increased compatible systems.
• Displays all pertinent parameters on the same screen for easy control and monitoring.
• Transmitter battery status meter.
• RF & audio meters.
• XLR & 1/4” audio outputs.
• Rugged metal construction.
• 100m(330ft.) operating range.(line-of-sight)

ACT50T Bodypack Transmitter

• Lightweight, compact size with sturdy metal housing.
• Antenna, mute button and XLR input connector are located on the top of transmitter.
• Backlit LCD displays various parameters and status.
• Innovatively designed battery cover allows easy access to operate buttons and prevents accidental operation.
• Mute button and remote-control jack is equipped for easy activation of mute function.
• PLL-synthesized technology enhances frequency stability and an interference-free working channel can be synchronized quickly and precisely by MIPRO’s patented ACT™ function.
• Can be directly matched to high-low input impedance for microphone and guitar without switching and the input sensitivity is adjustable.
• Mini-XLR input connector for quick-lock or screw-lock with lavaliere or headworn microphones and guitar.
• High efficiency, low power consumption and low spurious emissions transmitting circuit for long battery hours of 2 AA batteries.
• Adjustable belt clip allows wearing transmitter in up or down position.
