MIPRO ACT515T/ACT50T Wireless Lavalier System

The MIPRO's ACT515T/ACT50T is a wireless microphone system that includes ACT515T dual channel true diversity receiver with ACT50T wireless bodypack transmitter. The ACT515T is a dual channel true diversity 1U metal rack-mountable receiver with with RF and audio level indicators. It features one-touch scan & ACT sync channel setup technology, and has up to 8 preset compatible channels per bandwidth. ACT50T miniature wireless bodypack transmitter is a small and lightweight transmitter with sturdy metal housing. The transmitter has a mute switch, a mini-XLR connector, an antenna on the top, and a back-lit LCD panel with numerous metrics shown. The transmitter can be worn in either an up or down position with the adjustable belt clip.

ACT515T dual channel true diversity receiver

• Professional wireless microphone system with EIA standard 1U rack mountable design
• Advanced true diversity technology for best reception quality for wireless microphones
• Up to 8 preset compatible channels per bandwidth
• One-touch Scan & ACT sync channel setup technology
• Advanced multi-function backlit LCD displays all parameters on the same screen
• Dual "Pilotone & NoiseLock" circuits minimize interference
• Industry’s only interference “warning” indicator
• Adjustable squelch for managing interferences
• RF & audio level indicators
• Transmitter battery level indicator
• Receiver provides bias for booster
• Up to 100m (330 ft.) operating range (line-of-sight)
• ACT 5 series of wireless microphone system offers unbeatable price/performance ratio.

ACT50T wireless bodypack transmitter

• Backlit LCD displays various parameters and status.
• Innovatively designed battery cover allows easy access to operate buttons and prevents accidental operation.
• Mute button and remote-control jack is equipped for easy activation of mute function.
• PLL-synthesized technology enhances frequency stability and an interference-free working channel can be synchronized quickly and precisely by MIPRO’s patented ACT™ function.
• Can be directly matched to high-low input impedance for microphone and guitar without switching and the input sensitivity is adjustable.
• Mini-XLR input connector for quick-lock or screw-lock with lavaliere or headworn microphones and guitar.
• High efficiency, low power consumption and low spurious emissions transmitting circuit for long battery hours of 2 AA batteries.
