MIPRO ACT515T/ACT50H Wireless Handheld System

The MIPRO's ACT515T/ACT50H is a wireless microphone system that includes ACT515T dual channel true diversity receiver with two ACT50H wireless handheld microphone. The ACT515T is a dual channel true diversity 1U metal rack-mountable receiver with with RF and audio level indicators. It features one-touch scan & ACT sync channel setup technology, and has up to 8 preset compatible channels per bandwidth. ACT50H is a handheld transmitter with unique multi-layered steel grilles that protect the capsule from impact, anti-roll, and pop noise while still providing transparent sound clarity. It has interchangeable capsule modules with quality condenser or dynamic choices, which proprietary true condenser capsule provides high fidelity, wide dynamic range, excellent feedback rejection, and transparent sound quality.

ACT515T dual channel true diversity receiver

• Professional wireless microphone system with EIA standard 1U rack mountable design
• Advanced true diversity technology for best reception quality for wireless microphones
• Up to 8 preset compatible channels per bandwidth
• One-touch Scan & ACT sync channel setup technology
• Advanced multi-function backlit LCD displays all parameters on the same screen
• Dual "Pilotone & NoiseLock" circuits minimize interference
• Industry’s only interference “warning” indicator
• Adjustable squelch for managing interferences
• RF & audio level indicators
• Transmitter battery level indicator
• Receiver provides bias for booster
• Up to 100m (330 ft.) operating range (line-of-sight)
• ACT 5 series of wireless microphone system offers unbeatable price/performance ratio.

ACT50H wireless handheld microphone

• Rugged, ergonomically designed metal housing.
• Unique sturdy multi-layered steel grilles not only protect the capsule against impact, anti-roll and pop noise, but also ensure transparent sound clarity.
• Interchangeable capsule module with premium condenser or dynamic options for easy and fast changeovers.
• Proprietary lockable silent on/off switch to avoid accidental power-off during performance.
• Patented, integrated grille and battery housing design enable fast and easy 2 AA battery installation and replacement.
• Impact-resistant battery compartment holds 2 AA batteries with color-coded rings for easy channel identification on stage.
• LCD displays working channel, battery status indicator, and error code messages
• Low spurious PLL-synthesized technology enhances frequency stability and reliability.
• One-touch ACT syncs the transmitter and receiver frequency automatically.
• Maximum 140dB SPL is achieved by the proprietary high dynamic range modulation circuitry.
