MIPRO ACT515B/ACT52T Wireless Lavalier System

The MIPRO's ACT515B/ACT52T is a wireless microphone system that includes ACT-515B single channel receiver and a ACT-52T wireless lavalier transmitter. The ACT-515B features a red/green backlit LCD on the control panel for easy operation and is a useful and user-friendly option. These transmitters include MIPRO's newest ECM capsule module, which provides the listener with an extraordinarily clear and accurate audio image. It also delivers dependable performance at an economical price for stage, karaoke, and PA applications.

 ACT-515B Single Channel Receiver

• ACT-515 is an EIA standard 19” 1/2-unit true diversity receiver.
• Receiver provides bias voltage for MIPRO antenna systems to enhance reception range and signal stability.
• Dual "PiloTone & NoiseLock" circuits minimize interference.
• Backlit LCD displays group, channel, frequency RF & audio strength, A/B antenna, transmitter battery status, interference warning indicator & panel lock.
• Backlit LCD is lit in green when signal is received or button pressed. Backlit LCD is lit in red when no signal or button pressed. Easy to identify working mode (green) and standby mode (red) during performance.
• Balanced XLR / unbalanced 1/4 " audio output jack, output level switch and DC input are on the rear panel.
• UHF PLL-synthesized technology for enhanced RF stability, lowered spurious emissions and increased frequency agility. One-touch Autoscan for a clear, interference-free channel.
• 80 preset condition-free channels and 8 user-defined channels can be saved & recalled
• Adjustable ‘SQ’ for higher sensitivity to increase receiving distance or lower sensitivity to reduce interference.
• Adjust SQ when Interference warning indicator is lit for ideal sensitivity level

ACT 52T Bodypack Wireless Transmitter

• Lightweight, compact size with sturdy metal housing.
• Antenna, mute button and XLR input connector are located on the top of transmitter.
• Backlit LCD displays various parameters and status.
• Innovatively designed battery cover allows easy access to operate buttons and prevents accidental operation.
• Mute button and remote-control jack is equipped for easy activation of mute function.
• PLL-synthesized technology enhances frequency stability and an interference-free working channel can be synchronized quickly and precisely by MIPRO’s patented ACT™ function.
• Can be directly matched to high-low input impedance for microphone and guitar without switching and the input sensitivity is adjustable.
• Mini-XLR input connector for quick-lock or screw-lock with lavaliere or headworn microphones and guitar.
• High efficiency, low power consumption and low spurious emissions transmitting circuit for long battery hours of 2 AA batteries.
• Adjustable belt clip allows wearing transmitter in up or down position.
