MIPRO ACT515B/ACT52H Wireless Handheld System

The MIPRO's ACT515B/ACT52H is a wireless microphone system that includes ACT-515B single channel receiver and a ACT-52H handheld wireless microphone transmitter. The ACT-515B features a red/green backlit LCD on the control panel for easy operation and is a useful and user-friendly option. These transmitters include MIPRO's newest ECM capsule module, which provides the listener with an extraordinarily clear and accurate audio image. It also delivers dependable performance at an economical price for stage, karaoke, and PA applications.

 ACT-515B Single Channel Receiver

• ACT-515 is an EIA standard 19” 1/2-unit true diversity receiver.
• Receiver provides bias voltage for MIPRO antenna systems to enhance reception range and signal stability.
• Dual "PiloTone & NoiseLock" circuits minimize interference.
• Backlit LCD displays group, channel, frequency RF & audio strength, A/B antenna, transmitter battery status, interference warning indicator & panel lock.
• Backlit LCD is lit in green when signal is received or button pressed. Backlit LCD is lit in red when no signal or button pressed. Easy to identify working mode (green) and standby mode (red) during performance.
• Balanced XLR / unbalanced 1/4 " audio output jack, output level switch and DC input are on the rear panel.
• UHF PLL-synthesized technology for enhanced RF stability, lowered spurious emissions and increased frequency agility. One-touch Autoscan for a clear, interference-free channel.
• 80 preset condition-free channels and 8 user-defined channels can be saved & recalled
• Adjustable ‘SQ’ for higher sensitivity to increase receiving distance or lower sensitivity to reduce interference.
• Adjust SQ when Interference warning indicator is lit for ideal sensitivity level

ACT-52H Handheld Wireless Microphone Transmitter

• Rugged, ergonomically designed metal housing.
• Unique sturdy multi-layered steel grilles not only protect the capsule against impact, anti-roll and pop noise, but also ensure transparent sound clarity.
• Interchangeable capsule module with premium condenser or dynamic options for easy and fast changeovers.
• Proprietary true condenser capsule exhibits high fidelity, wide dynamic range, fast transient responses, good feedback rejection, accurate sound image characteristics, transparent sound quality, and withstands maximum SPL.
• Proprietary dynamic capsule exhibits low handling & impact noise characteristics.
• Proprietary lockable silent on/off switch to avoid accidental power-off during performance.
• Patented, integrated grille and battery housing design enable fast and easy 2 AA battery installation and replacement.
• Impact-resistant battery compartment holds 2 AA batteries with color-coded rings for easy channel identification on stage.
• LCD displays working channel, battery status indicator, and error code messages
• Low spurious PLL-synthesized technology enhances frequency stability and reliability.
• One-touch ACT syncs the transmitter and receiver frequency automatically.
• Maximum 140dB SPL is achieved by the proprietary high dynamic range modulation circuitry.
