MIPRO ACT312B/ACT32T Wireless Lavalier System

MIPRO's ACT 3-Series systems are designed to withstand harsh environments while providing excellent RF reliability and transparent audio performance in a wide range of professional settings and applications. The ACT 3-Series wireless systems are low-cost UHF frequency agile diversity systems that do not sacrifice features or performance. The ACT-312/ACT32T is a UHF frequency agile dual channel half rack receiver with a ACT-32T bodypack wireless transmitter.

ACT-312 Dual Channel UHF Radio Mic Receiver

• EIA standard 1/2U metal rack-mountable receiver
• Balanced XLR / unbalanced 1/4 " audio output jack, output level switch and DC input are on the rear panel. One mixed-output switch is available for dual-channel receivers
• Industry’s only RF interference warning indicator for proper adjustments of the SQ level
• Increase sensitivity to extend receiving range; decrease the sensitivity to reduce interference
• Receiver provides bias for booster where MIPRO antenna systems can be added for extended receiving range and stability
• DC input jack accepts 12~15V power supply

ACT-32T Bodypack Wireless Transmitter

• Lightweight, compact size with sturdy plastic housing.
• Mute switch, mini-XLR connector and antenna connection are found on the top.
• Backlit LCD displays various parameters and status.
• Mute button with remote-control jack for easy activation of mute function.
• Can directly match to high-low input impedance for microphone or guitar without switching.
• Mini-XLR input with secure screw lock connector for lavaliere / headworn mics and guitar.
• Adjustable belt clip allows wearing transmitter in up or down position.

High-efficiency circuitry design provides 12~14 hours of operation from 2 AA batteries (depending on the battery quality).
